Series 'HCI' Metal Horizontal Pump
Application
The Series 'HCI' horizontal pumps feature compact close-coupled design. A high efficiency semi-open impeller allows for less clogging and quick cleaning. Since the components are cast, there are no welds to break. Also, cast construction provides a superior corrosion resistance over similar welded styles.
Materials
Cast iron, Cast SS316
Performance
10-160 gpm
Specifications
The Series 'HCI' horizontal pumps feature compact close-coupled design. A high efficiency semi-open impeller allows for less clogging and quick cleaning. Since the components are cast, there are no welds to break. Also, cast construction provides a superior corrosion resistance over similar welded styles. The Series 'HCI' pumps feature the most widely accepted industrial mechanical seal designated as Type 21. This seal is mounted "inboard" and, thus tends to be self-cleaning. The seal is available as a single seal solution flush or as a double seal which uses external liquid as a flush. By adding the double seal, these pumps can better handle abrasives / salts and be protected from running dry. Pumps are constructed of cast iron for maximum corrosion resistance. Gasket is a synthetic fiber with cast iron. Both the single and double inboard seal assemblies are available in either EPDM or FKM. Double seal is recommended for flushing the seal chamber with water when abrasives are present or for certain other critical conditions. The SS shaft adapter protects the motor shaft and allows the use of standard NEMA motor. Motors are 3450 RPM @ 60Hz or 2850 RPM @50 Hz, TEFC or EXP. Single phase TEFC motors include 8 ft. (2.4m) line cord.
Features
Flows to 160 U. S. gpm or 90 ft. TDH @ 60 Hz (510 LPM or 19.5m @ 50 Hz)
Single or double mechanical seal Carbon/ceramic FKM or EPDM elastomers
Centrifugal, quiet, vibration-free
Motors are standard NEMA 'C' face TEFC or explosion-proof
Cast iron solution contact
SS 316 shaft adapter
Includes steel mounting base
The Series 'HCI' horizontal pumps feature compact close-coupled design. A high efficiency semi-open impeller allows for less clogging and quick cleaning.
Since the components are cast, there are no welds to break. Also, cast construction provides a superior corrosion resistance over similar welded styles.
The Series 'HCI' pumps feature the most widely accepted industrial mechanical seal designated as Type 21. This seal is mounted "inboard" and, thus tends to be self-cleaning. The seal is available as a single seal solution flush or as a double seal which uses external liquid as a flush.
By adding the double seal, these pumps can better handle abrasives / salts and be protected from running dry. Pumps are constructed of cast iron for maximum corrosion resistance. Gasket is a synthetic fiber with cast iron.
Both the single and double inboard seal assemblies are available in either EPDM or FKM. Double seal is recommended for flushing the seal chamber with water when abrasives are present or for certain other critical conditions. The SS shaft adapter protects the motor shaft and allows the use of standard NEMA motor. Motors are 3450 RPM @ 60Hz or 2850 RPM @50 Hz, TEFC or EXP. Single phase TEFC motors include 8 ft. (2.4m) line cord.
